BoTouch Plastic (BTK / BTK-IP) designed for use with capacitive touch screens (from 4.3" to 10.4")
BoTouch Aluminium (BTA) designed for use with resistive touch screens (from 5.7" to 12.1")
project-specific variants on request
enclosure front / front membrane: project-specific printing
rear hood / enclosure frame fitted with clamps for panel installation
project-specific display retaining plate made of aluminium (the following are required for preparation work: sample, CAD data or a datasheet for the touch/display combination.)
starter kits are available consisting of enclosure incl. mounted display for various designs

Product Information

Characteristics
Colour	BTK / BTK-IP: black, similar to RAL 9005; BTA: customer-specific
Protection Class	BTK-IP: IP 65/DIN EN 60529 BTK / BTA: Up to IP 65/DIN EN 60529 for the installation area
Enclosure Material	Rear hood: galvanised sheet steel Rear panel: anodised aluminium BTK enclosure frame: PC UL 94 V0 BTK-IP enclosure frame: PA 6.6 GF 30 UL 94 V0 BTA front frame: aluminium (anodised or powder-coated)

Individual enclosures, optimised for the installation ofcapacitive and resistive touch screens

Using an installation process which istrademarked by BOPLA, the display is fixedby means of a retaining plate.

The installation process efficientlycompensates for dimensional andprocessing tolerances, and also for theeffects of thermal expansion or mechanicalloads such as vibrations.

BTK(-IP)： BTK(-IP): Optimal touch function byglueing the display to the glass pane usingthe optical bonding process.

BTK(-IP):BTK(-IP): A 2 mm thick mineral glass panewhich is backprinted and designed forspecific projects ensures optimal protectionand a clear view of the display.

Control panel mounting enclosure withaluminium front panel provides sufficientspace for modern HMI solutions

BTA: The project-specific aluminium frontframe offers a wide range of options forindividual designs. Special sizes are alsopossible.

BTK-IP: This version provides ingressprotection of IP 65 for the enclosure and tothe installation area; BTK / BTA = IP 65 tothe installation area only
