Technical Data
Material	DIN EN 1706 ENAC-ALSi 12 ( Fe )
Colour	Powder coating, Body: RAL 7038, agate grey, Front frame: RAL 7043, traffic grey B, special colour on request
Ingress protection	IP 65 to EN 60529 with transparent cover IP 54
Impact resistance	7 Joule to EN 60079-0 (enclosure body)
Temperature range	PU (polyurethane) seal (std.): -40°C to +90°C CR (chloroprene) seal: -40°C to +100°C VMQ (silicone) seal (optional): -60°C to +130°C Transparent lid -10°C to +50°C
Other versions on request	Silicone lid seal

Product Range
Order-No.	Dimensions H x W x D (mm)	Front panel
	W X L X H ( m m )
13.05 00 00	230 X 100 X 128	10.01 30 05
13.07 00 00	260 X 160 X 108	10.01 30 07
13.08 00 00	360 X 160 X 108	10.01 30 08
13.09 00 00	560 X 160 X 108	10.01 30 09
13.10 00 00	230 X 200 X 128	10.01 30 10
13.11 00 00	230 X 200 X 198	10.01 30 10
13.12 00 00	230 X 330 X 128	10.01 30 12
13.13 00 00	230 X 330 X 198	10.01 30 12
13.14 00 00	230 X 400 X 128	10.01 30 14
13.15 00 00	230 X 400 X 242	10.01 30 14
13.16 00 00	230 X 600 X 128	10.01 30 16
13.17 00 00	230 X 280 X 130	10.01 30 17
13.20 00 00	310 X 400 X 128	10.01 30 20
13.21 00 00	310 X 400 X 198	10.01 30 20
13.22 00 00	310 X 600 X 128	10.01 30 22
13.23 00 00	310 X 600 X 198	10.01 30 22
13.24 00 00	310 X 400 X 244	10.01 30 20
13.25 00 00	310 X 400 X 158	10.01 30 20
*Please specify handles, accessories or configuration modification if you need.
