Characteristics | ||||
Colour | Lateral trims, front and base elements light grey, similar to RAL 7035; front lid FD…G, crystal-clear, rear elements agate grey, similar to RAL 7038; special colours on request. | |||
Protection Class | IP 66/DIN EN 60529; with air vents IP 30/DIN EN 60529 | |||
Enclosure Material | ABS; PC (only FD…G), seal made of CR; for details see Technical Information |
This modular enclosure system offers adaptability andprotection class IP 66
All front, basic and rear elements can becombined in one basic size. Thecombination of “front with rear lid” can becreated even without a basic element. |
With a suitable enclosure size, the baseelements with air vents can be positionedaccording to the convection requirements. |
The integrated hinged quick-releasecatches allow left-hand or right-handopening between each system component. |
Fitting of the enclosure does not requiretools. Dismantling is possible with aslotted-head screwdriver |
Each hinged catch can be protectedagainst unauthorised access by lock boltsor a lead seal. The fronts can be closed bymeans of a cylinder catch |
Circuit boards are fixed either by screwbosses in the rear lid or in guide grooves inthe basic element |
19" subracks according to DIN EN60297-3-101 can be fitted in suitableenclosure configurations. |
Wall mounting is easy with the use ofoptional wall brackets.
|
The handle – available as an accessory –can be used to tip up the enclosure.
|
